Dell R650 Server

Low profile, high-density processing

Ideal for traditional corporate IT, database and analytics, virtual desktop infrastructure, as well as AI/ML and HPC, the Dell EMC PowerEdge R650 offers high speed memory and capacity, and I/O bandwidth and storage.

The R650 is designed with a cyber-resilient architecture, allowing you to operate your workloads on a secure platform. A dual-socket/IU rack server, it supports 8 channels of memory per CPU, up to 32 DDR4 DIMMs, PCIe Gen 4 and up to 12 NVMe drives.

Dell R650 Specifications

Processor

  • Up to two 3rd generation Intel Xeon Scalable processors

Drive Bays

  • Front drive bays: Up to 10 x 2.5” SAS/SATA (HDD/SSD) with up to 8 NVMe SSD max 58TB or up to 10 NVMe drives max
    64TB, or up to 4 x 3.5” SAS/SATA HDD max 48TB
  • Rear drive bays: Up to 2 x 2.5” SAS/SATA (HDD/SSD), NVMe SSD max 12TB
    Optional DVD-ROM, DVD+RW

Front Ports

  • 1 x Dedicated iDRAC Direct micro-USB
  • 1 x USB 2.0
  • 1 X VGA

Rear Ports

  • 1 x USB 2.0
  • 1 x Serial (optional)
  • 1 x USB 3.0
  • 2 x RJ-45
  • 1 x VGA (optional for liquid cooling configuration

Security

  • Cryptographically signed firmware
  • Secure Boot
  • Secure Erase
  • Silicon Root of Trust
  • System Lockdown (requires iDRAC9 Enterprise or Datacenter)
  • TPM 1.2/2.0 FIPS, CC-TCG certified, TCM 2.0 option

Cooling Options

  • Air cooling, optional processor liquid cooling

PowerEdge R650 Dimensions & Weight

  • Height – 42.8 mm (1.7 inches)
  • Width – 482 mm (18.97 inches)
  • Max depth: 809 mm (31.85 inches) without bezel and 822.84 mm (32.39 inches) with bezel

Comparison Chart - R640, R650, R740 & R750

Model Form Factor Processor Cores/Processor Memory
R640Rack 1UUp to two Intel Xeon Scalable processorsUp to 2824 DDR4 DIMM slots, Supports RDIMM /LRDIMM, speeds up to 2666MT/s, 3TB max
Up to 12 NVDIMM, 192 GB Max
Supports registered ECC DDR4 DIMMs only
R650Rack 1UUp to two 3rd Generation Intel Xeon Scalable processorsUp to 4032 DDR4 DIMM slots, supports RDIMM 2 TB max or LRDIMM 4 TB max, speeds up to 3200 MT/s
Up to 16 Intel Persistent Memory 200 series (BPS) slots, 8 TB max
Supports registered ECC DDR4 DIMMs only
R740Rack 2UUp to two Intel Xeon Scalable processorsUp to 2824 DDR4 DIMM slots, Supports RDIMM /LRDIMM, speeds up to 2666MT/s, 3TB max
Up to 12 NVDIMM, 192 GB Max
Supports registered ECC DDR4 DIMMs only
R750Rack 2UUp to two 3rd Generation Intel Xeon Scalable processorsUp to 4032 DDR4 DIMM slots, supports RDIMM 2 TB max or LRDIMM 8 TB max, speeds up to 3200 MT/s
Up to 16 Intel Persistent Memory 200 series (BPS) slots, 8 TB max
Supports registered ECC DDR4 DIMMs only
