Dell PowerEdge R660 Server
Full-Featured Enterprise Server
The R660 handles the most demanding applications
- Choose 4th Generation Intel Xeon Scalable and Intel Xeon Max processors or up to two 5th Generation Intel Xeon Scalable processors
- Up to three PDIe slots
- 32 DDR5 DIMM slots
- 1U rack height
Pricing Information
Prices will vary depending on the configuration of the device and the quantity of the devices you are looking to purchase. If you would like a formal quote, contact us.
Other Get a Quote Options:
Use our chat or call us at 1-866-230-MOJO (6656)
PowerEdge R660 Technical Guide
PowerEdge Rack Servers Quick Reference Guide
R660 Dimensions
- Height – 42.8 mm (1.68 inches)
- Width – 482 mm (18.97 inches)
- Depth: 809.04 mm (31.85 inches) without bezel; 822.88 mm (32.39 inches) with bezel
Processor
- Up to two 4th Generation Intel Xeon Scalable or Intel Xeon Max processors
- Up to two 5th Generation Intel Xeon Scalable processors
Drive Bays
- Front bays:
- Up to 10 x 2.5-inch, SAS/SATA/NVMe (HDD/SSD) max 153.6 TB
- Up to 8 x 2.5-inch, SAS/SATA/NVMe, (HDD/SSD) max 122.88 TB
- Up to 14 x EDSFF E3.S Gen5 NVMe (SSD) max 179.2 TB
- Up to 16 x EDSFF E3.S Gen5 NVMe (SSD) max 204.8 TB
- Rear bays:
- Up to 2 x 2.5-inch, SAS/SATA/NVMe max 30.72 TB
- Up to 2 x EDSFF E3.S Gen5 NVMe (SSD) max 25.6 TB
Takes on Dense Database Analytics and High-Density Virtualization.
The R660 has multiple chassis designs to help you achieve maximum efficiency for your workloads and objectives. With the R660, you get performance and versatility - interchangeable components allow you to tailor the server to your needs at any time.
All Products Come With A Warranty
Product Warranty for New OEM Products:
All products quoted are covered by the Original Equipment Manufacturer's warranty. If you would like specific warranty details, start a chat with us, call us at 1-866-223-9313 or reach out to your sales representative to discuss options.
Product Warranty for Used and Secondary Market Products:
All products quoted are covered by Mojo Systems’ Limited 90-day warranty.
Additional warranty options are available upon request:
- Extend your Mojo warranty to 2, 3, 4, 5+ years
- Enhance your Mojo warranty options with Mojo’s Third Party Hardware Support
If you would like to discuss Mojo’s product warranty, start a chat with us, call us at 1-866-223-9313 or reach out to your sales representative to discuss options.
Shipping Information
Shipping rates for this product will vary depending on the shipping method (overnight, 2-day, ground, etc.).
For specific shipping rates, start a chat with us, call us, or reach out to your sales representative to discuss options.
Mojo Systems offers personalized support at up to 70% off OEM prices. Choose 9/5/NBD, 7/24/4 or a customized service level agreement.
Cancellation/Return Policies
Cancellation or Return Policy for New OEM Products:
All products/services quoted are covered by the Original Equipment Manufacturer's cancellation and return policy.
Cancellation or returns are subject to the approval by the manufacturer and requests must be received by the manufacturer within 30 days of the order shipping date.
If a cancellation or return request is approved, the manufacturer may require a restocking/cancellation fee.
If you need to cancel or return your purchase, start a chat with us, call us at 1-866-223-9313 or reach out to your sales representative to discuss options.
Cancellation or Return Policy for Used or Secondary Market Products:
All products/services quoted are covered by Mojo Systems’ cancellation or return policy.
Cancellations or returns are subject to the approval by Mojo Systems and will only be considered on unopened boxes.
Cancellation or return requests must be received by Mojo Systems within 30 days of the order shipping date.
If a cancellation or return request is approved, Mojo may require a restocking/cancellation fee.
If you need to cancel or return your purchase, start a chat with us, call us at 1-866-223-9313 or reach out to your sales representative to discuss options.
Comparison Chart
R440, R450, R470 & R640, R650, R660
| Model | Form Factor | Processor | Cores/Processor | Memory |
|---|---|---|---|---|
| R440 | Rack 1U | Up to two Intel Xeon Scalable processors | Up to 28 | 16 DDR4 DIMM slots, Supports RDIMM /LRDIMM |
| R450 | Rack 1U | Up to two 3rd Generation Intel Xeon Scalable processors | Up to 24 | 16x RDIMM |
| R470 | Rack 1U | One Intel Xeon 6 processor | Up to 144 | 16 DDR5 DIMM slots, RDIMM, speeds up to 6400MT/s Supports registered ECC DDR5 DIMMs only |
| R640 | Rack1U | Up to two Intel Xeon Scalable processors | Up to 28 | 24 DDR4 DIMM slots, Supports RDIMM /LRDIMM, speeds up to 2666MT/s, 3TB max Up to 12 NVDIMM, 192 GB Max Supports registered ECC DDR4 DIMMs only Supports registered ECC DDR4 DIMMs only |
| R650 | Rack1U | Up to two 3rd Generation Intel Xeon Scalable processors | Up to 40 | 32 DDR4 DIMM slots, supports RDIMM 2 TB max or LRDIMM 4 TB max, speeds up to 3200 MT/s Up to 16 Intel Persistent Memory 200 series (BPS) slots, 8 TB max Supports registered ECC DDR4 DIMMs only |
| R660 | Rack 1U | Up to two 4th Generation Intel® Xeon® Scalable or Intel® Xeon® Max processors or Up to two 5th Generation Intel Xeon Scalable processors | Up to 56 or Up to 64 | 32 DDR5 DIMM slots, supports RDIMM 8 TB max, speeds up to 4800 MT/s Speeds up to 4800 MT/s on the 4th Generation Intel Xeon Scalable or Intel Xeon Max processors Speeds up to 5600 MT/s on the 5th Generation Intel Xeon Scalable processors Supports registered ECC DDR5 DIMMs only |
