Dell R750 Server
An Enterprise Server That Delivers
Ideal for data center standardization on a wide range of demanding workloads, the R750 can hold twice as many NVMe drives as the R650 and up to 8 TB of LRDIMM memory.
The Dell PowerEdge R750 is all about application performance and acceleration. It supports 8 channels of memory per CPU, and up to 32 DDR4 DIMMs @ 3200 MT/s speeds. Automated features and built-in telemetry streaming give you added productivity and better server management. And, its cyber-resilient architecture integrates security into every phase in the lifecycle.
Dell R750 Specifications
Dell PowerEdge R750 Specs
PowerEdge R750 offers improved air-cooling features and optional Direct Liquid Cooling to support increasing power and thermal requirements.
Server Processor Information
- Up to two 3rd Generation Intel Xeon Scalable processors, with up to 40 cores per processor
Storage
- Front Bays
- Up to 12 x 3.5-inch SAS/SATA (HDD/SSD) max 192 TB
- Up to 8 x 2.5-inch NVMe (SSD) max 122.88 TB
- Up to 16 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 245.76 TB
- Up to 24 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 368.84 TB
- Rear bays:
- Up to 2 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 30.72 TB
- Up to 4 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 61.44 TB
Dell R750 Memory
- 32 DDR4 DIMM slots, supports RDIMM 2 TB max or LRDIMM 8 TB max, speeds up to 3200 MT/s
- Up to 16 Intel Persistent Memory 200 series (BPS) slots, 8 TB max
- Supports registered ECC DDR4 DIMMs only
PowerEdge R750 Dimensions & Weight
- Height – 86.8 mm (3.41 inches)
- Width – 482 mm (18.97 inches)
- Depth – 758.3 mm (29.85 inches) - without bezel
- 772.14 mm (30.39 inches) - with bezel
Comparison Chart - R640, R650, R740 & R750
Model | Form Factor | Processor | Cores/Processor | Memory |
---|---|---|---|---|
R640 | Rack 1U | Up to two Intel Xeon Scalable processors | Up to 28 | 24 DDR4 DIMM slots, Supports RDIMM /LRDIMM, speeds up to 2666MT/s, 3TB max Up to 12 NVDIMM, 192 GB Max Supports registered ECC DDR4 DIMMs only |
R650 | Rack 1U | Up to two 3rd Generation Intel Xeon Scalable processors | Up to 40 | 32 DDR4 DIMM slots, supports RDIMM 2 TB max or LRDIMM 4 TB max, speeds up to 3200 MT/s Up to 16 Intel Persistent Memory 200 series (BPS) slots, 8 TB max Supports registered ECC DDR4 DIMMs only |
R740 | Rack 2U | Up to two Intel Xeon Scalable processors | Up to 28 | 24 DDR4 DIMM slots, Supports RDIMM /LRDIMM, speeds up to 2666MT/s, 3TB max Up to 12 NVDIMM, 192 GB Max Supports registered ECC DDR4 DIMMs only |
R750 | Rack 2U | Up to two 3rd Generation Intel Xeon Scalable processors | Up to 40 | 32 DDR4 DIMM slots, supports RDIMM 2 TB max or LRDIMM 8 TB max, speeds up to 3200 MT/s Up to 16 Intel Persistent Memory 200 series (BPS) slots, 8 TB max Supports registered ECC DDR4 DIMMs only |
